Newlong Industrial (NLI) DS-2(II) & DS-2W
Single Needle, Plain Sew, Bag Closer for materials such as Multi-wall Paper, Polypropylene (PP) & Jute Bags. The machine is equipped with Mechanically Operated Continuously Running Thread Cutter.
The standard needle used by the DS2 (II) is: Organ 124×2 DRx2 #25 (Newlong B02001 part number)
Newlong Industrial (NLI) DS-2(II) & DS-2W Single Needle, Plain Sew, Bag Closer for closing Rice
Technical Specifications / Caracteristicas Tecnicas
| Model | DS-2Ⅱ | DS-2W |
| Max. Speed ※ | 1,400rpm | |
| Seam |
Double thread chain stitch (Type 401) |
|
| Stitch Width | 7-12mm | |
| Bag Material | Cotton・Paper・Jute・PP | Paper・PP |
| Thickness | Jute Bag 10mm | Paper bag 6P with a tuck |
| Cutter | Half automatic thread cutter | |
| Needle | DR×2 #25 | DR-H30 #26 |
| Oiling | by hand ・ Oiler | |
| Oil | Machine oil #10 | |
| weight | 40.0kg | |
| Feature | – | Double needle |
| Related Machines | A type・B type (conveyor) | |
※depending on sewing material and operation
Newlong Industrial Sewing Machine
Made in Japan
